Dustless Anchoring - The ICCONS Blue Banger Hanger

27 June 2019
Dustless Anchoring - The ICCONS Blue Banger Hanger
On this page

Introducing the ICCONS Blue Banger Hanger, Australia's #1 Deck Anchor insert.

Blue Banger Hangers have been engineered to save you time and money and are backed by industry-leading test approvals, design and application engineering. Each insert handles multiple threaded rod diameters and installs in a fraction of the time of post-installed anchors.

Blue Banger Hangers are the insert of choice for the building services trades including HVAC, Electrical, Plumbing, Piping and Fire Sprinkler Contractors. The multi-thread, cast-in anchor for wood-form and steel deck are suitable for cracked and uncracked concrete, dramatically save install time when compared to traditional methods, eliminate worker exposure to silicosis and other OHS hazards.

  • Reduce Labour Costs
  • Reduce Inventory close-up of the ICCONS Steel Deck Insert Blue Banger Hangerclose-up of the ICCONS Pour in Place Insert Blue Banger Hanger
  • Fast and Secure Install
  • Easily Change Rod Sizes
  • No Drilling Concrete
  • No Using Rod Couplers
  • No Special Inspection
  • No Installer Error

For Wood Formed Concrete Decks

infographic promoting ICCONS' Pour in Place inserts, promoting no snags, 55% larger base, and new seals

ICCONS® Pour-in-Place (PIP) inserts are used on wood form poured decks and installed prior to pouring concrete, reducing installation and material costs.

Machined Steel Insert with Large Flanged Head and Nails

  • Angled ridges protect the head of the insert from rebar during deck work.
  • The larger plastic base ensures that the insert is installed flush to the deck to prevent concrete from contaminating the inner threads during the pour.
  • UL plenum rated for use in ceiling cavity spaces.
  • Slurry seal safeguards the internal threads during the concrete pour.
  • Provides excellent shear values for overhead attachments.
  • Insert installed height of two inches complies with typical design specifications.
  • Nails easily break off.

Multiple Internal Threads

  • Reduces inventory, each insert can accommodate M8, M10 & M12 threaded rod sizes.
  • Allows for threaded rod size changes after inserts are installed.
  • Internal threads eliminate the need and cost of couplings.

For Steel Formed Concrete Decks

infographic promoting the ICCONS Steel Deck Insert Blue Banger Hanger

ICCONS® Steel Deck Inserts (SDI) are installed prior to pouring, reducing installation and material costs and increasing strength values. Ideal for gravity & seismic anchorage!

Machined Steel Insert with Large Flanged Head

  • Provides excellent shear values for overhead attachments.
  • Patented grooved insert body prevents component separation even if the flute is broken off prior to pouring.
  • Fully cracked concrete tested for vertical and dynamic seismic loading.
  • Backed by: ICC Report ESR-3599 granted under AC446.

Three Inch Blue Plastic Sleeve

  • Keeps internal threads clean.
  • Extended length makes insert easy to locate even with fireproofing on deck underside.
  • The plastic sleeve provides guidance to align the threaded rod with matching internal female threads.
  • UL plenum rated for use in ceiling cavity spaces.

Multiple Internal Threads

  • Reduces inventory, each insert can accommodate M8, M10 & M12 threaded rod sizes.
  • Allows for threaded rod size changes after inserts are installed.
  • Internal threads eliminate the need and cost of couplings.

The Result?

ICCONS Blue Banger Hangers are Australias #1 Deck Anchor Insert. To read more about this incredible product as well as technical data and calculated cost savings, download the information brochure.
