Sleeve Anchors - Flush Head

Sleeve Anchors - Flush Head

Product Summary

The Flush Head Sleeve Anchor is a medium duty pre-assembled torque controlled expansion anchor consisting of a threaded plow bolt and a pressed carbon steel sleeve designed to expand when cone is tightened locking the sleeve against the wall of the hole. Features a flush head leaving the fixture with a more discrete /clean finish than a traditional hex head sleeve anchor. Ideal for various base materials such as concrete, solid brick or concrete block.

Add to Sitebox Available in 21 variations

Submit your Sitebox and an ICCONS representative will be in touch.

Find a dealer

Browse the ICCONS Dealer Network to find one near you.

Dealer Login
Show Related Products
Back
  • Product List
  • Features & Applications
  • Downloads

Specifications

Part No / Finish
Description
Drill Diameter
Head Type
Embedment Depth
Max Material Thickness
Quantity
UoM
Price

Zinc
SS
SAF08045
SLEEVE ANCHOR FLUSH HEAD 8 X 45
8
FLUSH HEX
35
10
100
SAF08045SS
SLEEVE ANCHOR FLUSH HEAD 8 X 45 SS
8
FLUSH HEX
35
10
100
SAF08070
SLEEVE ANCHOR FLUSH HEAD 8 X 70
8
FLUSH HEX
35
35
100
SAF08070SS
SLEEVE ANCHOR FLUSH HEAD 8 X 70 SS
8
FLUSH HEX
35
35
100
SAF08090
SLEEVE ANCHOR FLUSH HEAD 8 X 90
8
FLUSH HEX
35
55
100
SAF08090SS
SLEEVE ANCHOR FLUSH HEAD 8 X 90 SS
8
FLUSH HEX
35
55
100
SAF10040SS
SLEEVE ANCHOR FLUSH HEAD 10 X 40 SS
10
FLUSH HEX
35
6
100
SAF10045
SLEEVE ANCHOR FLUSH HEAD 10 X 45
10
FLUSH HEX
40
5
100
SAF10055
SLEEVE ANCHOR FLUSH HEAD 10 X 55
10
FLUSH HEX
40
15
100
SAF10060SS
SLEEVE ANCHOR FLUSH HEAD 10 X 60 SS
10
FLUSH HEX
40
20
100
SAF10065
SLEEVE ANCHOR FLUSH HEAD 10 X 65
10
FLUSH HEX
40
25
100
SAF10075SS
SLEEVE ANCHOR FLUSH HEAD 10 X 75 SS
10
FLUSH HEX
40
35
100
SAF10080
SLEEVE ANCHOR FLUSH HEAD 10 X 80
10
FLUSH HEX
40
40
100
SAF10095SS
SLEEVE ANCHOR FLUSH HEAD 10 X 95 SS
10
FLUSH HEX
40
55
100
SAF10100
SLEEVE ANCHOR FLUSH HEAD 10 X 100
10
FLUSH HEX
40
60
100
SAF12065
SLEEVE ANCHOR FLUSH HEAD 12 X 65
12
FLUSH HEX
50
15
100
SAF12075SS
SLEEVE ANCHOR FLUSH HEAD 12 X 75 SS
12
FLUSH HEX
50
25
100
SAF12080
SLEEVE ANCHOR FLUSH HEAD 12 X 80
12
FLUSH HEX
50
30
100
SAF12105
SLEEVE ANCHOR FLUSH HEAD 12 X 105
12
FLUSH HEX
50
55
100
SAF16075
SLEEVE ANCHOR FLUSH HEAD 16 X 75
16
FLUSH HEX
60
15
100
SAF16110
SLEEVE ANCHOR FLUSH HEAD 16 X 110
16
FLUSH HEX
60
50
100

Features & Applications

Features
• Strong, yet economical expansion anchor
• Flush head provide a more discrete or clean finish than a traditional sleeve anchor
• Pre-assembled for fast and simple installation
• Ideal for through fastening applications

Applications
• Ideal for fixing steel brackets, and timber structures to solid base materials
• Suitable in concrete
• Stone
• Solid brick
• Concrete block
